Students of Shiv Nadar School Noida conduct Lung Capacity Test and create low-cost prototype of air-filter

They have worked on developing an innovative air quality monitoring mechanism.

Written by Editorial Team |Published : November 12, 2017 4:40 PM IST

At a time when the air quality index (AQI) in Delhi NCR is at its worst, at around 450 on a scale of 500, grade six and nine students ofShiv Nadar School Noida (a not-for-profit initiative of the Shiv Nadar Foundation in K12 education) have initiated a drive to scientifically address the specific issue of air pollution. They have worked on developing an innovative air quality monitoring mechanism and have conducted lung capacity test to demonstrate the respiratory deterioration caused by pollution. They have also created a cost-effective prototype of air filter model and air humidifiers. This air filter model is equipped to remove solid pollutants like emission from products like paints, burning fuel, construction rubble as well as allergens like pollens and moulds.

On the innovative efforts of the students, Ms Shashi Banerjee, Principal, Shiv Nadar School Noida said, Air pollution is a threat to the society s health at large and the situation in Delhi NCR is getting worse day by day. Given this, our students and teachers came up with a well-thought-out experiment to spread awareness among people about the alarming level of air pollution due to the burning of crackers and solutions to help curb and monitor air pollution.This was done by showing the effect of the same on our lungs.

At Shiv Nadar School, it is our constant endeavour to inculcate innovation and problem-solving skills in students, thus leading to the development of a sound scientific temper. We challenge students to develop workable solutions for problems in their immediate environment making use of technology and deep understanding of scientific concepts. This is an initiative in the same direction, and I am happy to see the learning students have derived from it, said Col. Gopal Karunakaran, CEO, Shiv Nadar School.

Also Read

More News

Lung Function Test About the test, comparative analysis and results

The students created a scientific model to test the vital capacity of lungs of people of different age groups, before and after Diwali. Vital capacity (VC) is the maximum amount of air a person can expel from the lungs after maximum inhalation. A person's vital capacity can be measured by a wet or regular spirometer or a model created on the same principles. The spirometer model was created using a water can (filled with 5-litre water), a rubber tube and a large container to hold the water and can. The can was inverted on the container with a rubber tube inserted inside. The can was call liberated on a scale of 5 litres and marked with the equal divisions of 250 mL. People of different age groups and gender were asked to blow inside the rubber tube in one go (up to their maximum capacity). Did you know what are Lung Function Tests?

Blowing the air inside the tube allowed water to displace out of the can. The students measured the individual lung capacity by comparing it with the amount of water displaced from the can. They calculated the lung capacity by multiplying the number of divisions up to which water got displaced with 250 mL to find the lung capacity of each person. Read here hormone replacement therapy may combat decline in lung function in middle-aged women

The students collected data from over 100 people (before Diwali) and 56 people (after Diwali) and calculated the average result. The lung capacity was found to be very low in comparison to the ideal capacity level. The results also suggested that:

  • The lung capacity decreases with age and respiratory disorders (as shared by some people about their medical history).
  • People with an active lifestyle, following an exercise regime, showed better results (e.g sports teachers, students and parents actively involved in various sports)
  • People who smoke or are more exposed to air pollution on daily basis showed poor lung capacity.
  • There was an overall decrease in the lung capacity of people post-Diwali indicating the severe effect on lungs due to increasing level of smog and pollution.

Air collection mechanism- about the experiment and results

Grade nine students designed an air collection mechanism using a syringe and Arduino circuit to collect air samples at different heights with the help of hydrogen balloons. The air was collected inside the syringe connected with a circuit timed at various intervals, which was sent up into the air using hydrogen balloons. The collected air samples were then transferred in different syringes and sent to Central Pollution Control Board for analysis.Results of air quality monitoring test are as follows(This data is of the samples collected on 2nd November 2017 at around 5.00 pm at the Shiv Nadar School, Noida Campus)

Height of SamplingO3 (ppb)PM2.5 ( g/m3)PM10 ( g/m3)CO (ppm)SO2 (ppb)NO2 (ppb)AQI
Ground Level156.3184.9386.119.9435.1793249
5mt160.8190.05389.221.8440.3849257
10mt165.1197.4396.422.9452.1902264
15mt172.3203.6402.924.3459.2946271
20mt177.9210.1410.126.1468.8991278
30mt190.2221.3414.327.2481.31023284
40mt183.4216.3410.726.4471.5954276

Above data shows every pollutant - Ozone O3, Particulate matter 2.5 and 10, Carbon Monoxide CO, Sulphur Dioxide SO2 and Nitrogen Dioxide NO2 and the Air Quality Index (AQI) increased with height.

The students intend to do this experiment at different places and at greater heights.

The suggested measures by the students are as follows:

  • To focus on leading an active lifestyle and do deep breathing exercises every day to increase lung capacity.
  • To avoid exposure to the morning air and during peak hours due to increasing level of smog during the winter season.
  • To plant more trees in the surroundings
  • To carpool while commuting.
